滚筒式自动喷砂机
◆主要技术参数 Main technical parameters
|
机器型号 Model |
STR-9070/9080 |
STR-1010 |
|
工作舱尺寸 Internal size(mm) |
900×800×650 |
1000×1000×790 |
|
整机尺寸 Complete machine size(mm) |
900×1030×1750 |
1000×1540×1830 |
|
电源 Power |
220V 50Hz |
220V 50Hz |
|
机器照明灯 Machine floodlight |
一盏60W防爆灯 |
220V 13W节能灯 |
|
滚筒承重 Roller bearing |
10-30Kg |
10-30Kg |
|
分离器电机 Separator motor |
220V 50Hz 550W |
220V 50Hz 550W |
|
分离器风量 Separator air volume |
8.5m3/min |
8.5m3/min |
|
压缩空气源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
|
机器重量 Weight |
320kg |
380 kg |
◆产品特点 Product features
1. 设计新颖、美观大方、结构科学、操作方便;
2. 自动控制自动喷砂，具备定时喷砂，点动定位等功能;
3. 滚筒外径及喷枪数量可根据客户需求设计制作;
4. 即可手动，又可自动，喷砂品质好，一机多用。
1.novel design, beautiful and easy, scientific structure, convenient operation
2.Automatic control automatic gush arenaceous, have the point start timing gush arenaceous, positioning, and other functions;
3.Roller diameter and spray gun quantity can be designed according to the customer demand;
4.Can manual and automatic, gush arenaceous well, multi-use.
◆适用范围 Applicable scope
适用于大量小工件的手动或自动喷砂，例如：电木制品、螺丝、塑胶制
品、钮扣、拉链、压克力、机器零部件等;
Apply to lots of small the manual or automatic spray sand, for example: electric wood products, screw, plastic products, button, zipper, the force that press a gram, machine parts, etc.
